Equipment Description
Membrane bioreactor (MBR) treatment plant is the combination of a membrane process like microfiltration or ultrafiltration with a suspended growth bioreactor, and is now widely used for municipal and industrial wastewater treatment. The MBR treatment plant features high quality, outlet, lower running cost, high adjust ability, less sludge outcome, automatic operation and compact footprint. It can be used both for a small complete wastewater treatment system and a post-treatment for a large wastewater treatment plant.

Inlet/Outlet Water Quality

Item	Influent	Effluent
pH	6-9	6-9
COD (mg/L)	≤500	≤50
BOD(mg/L)	≤300	≤10
SS(mg/L)	≤100	≤10

Technical Properties

High Effluent Quality
Low Operating Costs
Strong Resistance to Shock Loads
Reduced Sludge Production
High Automation
Compact Footprint

Equipment Properties

Broad Application Scope: Effectively treats domestic wastewater and similar organic effluents (e.g. food processing, hospitality, or municipal sewage).
Durable Construction: Fabricated from anti-corrosive carbon steel, fiber-reinforced plastic (FRP), or stainless steel (304/316L) for exceptional corrosion resistance and aging resistance. 50+ year service life under standard operating conditions.
Simplified Installation & Operation: Plug-and-play design for rapid deployment with minimal civil engineering. Fully automated control via PLC systems, enabling unattended operation.

Application

Hospitality & Healthcare: Hotels, restaurants, sanatoriums, hospitals;
Residential Areas: Residential communities, villages, townships;
Transportation Hubs: Stations, airports, seaports, ships;
Industrial & Military: Factories, mines, military bases, tourist sites, scenic areas;
Factory, mining, military camp, scenic spots.
